LEADING CUSTOM ALUMINUMEXTRUSION MANUFACTURER

From mold design to precision CNC machining and surface treatment.
Providing one-stop aluminum profile solutions with 30 years of industry expertise.

Aluminum fence

Our heavy-duty aluminum fence and architectural perimeter fencing systems are precision-extruded from top-grade 6000-series aluminum alloys to deliver a sophisticated, weld-free security layout. Engineered to replace high-maintenance timber and rust-prone wrought iron, these modular fencing profiles feature excellent structural yield performance and exceptional rigidity under high wind pressures. Sealed with premium, UV-stable architectural coatings, they provide a lifetime of maintenance-free, rust-proof boundary isolation perfect for luxury estates and critical commercial properties.

Key Specifications & Parameters

Parameter Specification / Options
Product Name Modular Extruded Aluminum Fence & Boundary Barrier Systems
Material Grade 6063-T5, 6061-T6 (High-precision structural grade alloys)
Fencing Profiles Interlocking Privacy Slats, Industrial Pickets, Louvered Shading Panels, Heavy-Duty Post Columns
Profile Wall Thickness 1.5mm – 3.5mm (Reinforced structural configurations customized to project specs)
Surface Finish Options AkzoNobel Powder Coating, Weatherproof Wood Grain Sublimation, Satin Anodized
Standard Colors Matte Black, Dark Charcoal Grey, Oil Rubbed Bronze, Custom RAL Color Tones supported
Assembly Method Weld-free modular interlocking slots, internal spacing clips, concealed heavy-duty fasteners
Deep Processing CNC Precision Length Sawing, Pre-bored Mounting Guides, Slot Punching, Corner Routing

Product Applications

  • Upscale Estate Privacy Boundaries: High-end horizontal privacy slat barriers enclosing residential gardens, modern villas, and luxury suburban backyards.
  • Commercial Facility Security: Clean-line structural picket fencing networks protecting corporate parks, retail zones, and multi-family residential communities.
  • Compliant Pool Enclosures: Fully waterproof, chemical-resistant safety picket barriers designed to meet strict outdoor swimming pool ventilation and child-safety codes.
  • Industrial Equipment Screening: Durable architectural louver or panel systems engineered to beautifully enclose commercial HVAC chillers, transformers, and garbage collection docks.

Product FAQ

Q1: What makes an extruded aluminum fence superior to traditional timber or iron fencing options?

A1: Wrought iron fencing experiences severe rust when exposed to regular rain or coastal air, demanding constant wire brushing and repainting. Timber fence panels absorb moisture, which leads to rotting, warping, cracking, and termite damage. Our structural aluminum fence panels form a natural protective oxide layer that entirely prevents corrosion, delivering a lifetime of maintenance-free operation and significant long-term cost benefits.

Q2: How do your fencing profiles ensure exceptional resistance against severe outdoor weather and intense UV rays?

A2: Every batch of our extrusion profile components passes through multi-stage chemical surface cleaning and chromate-free pretreatment. We then apply architectural-grade AkzoNobel polymer powder coatings or advanced wood-grain sublimation finishes. This establishes a highly stable cross-linked surface barrier that blocks solar weathering, entirely avoiding peeling, chalking, or blistering in hot climates.

Q3: Is the field installation process complicated for contractors, and are specialized welding tools required?

A3: No, absolutely not. Our structural fencing systems feature a completely weld-free modular assembly layout. Individual fence slats, louvers, or pickets slide cleanly into pre-routed channel post slots and lock into position via internal spacing clips or hidden heavy-duty fasteners. This interlocking setup eliminates visible screw heads, simplifies field height scaling, and drastically cuts on-site labor times.

Q4: Can we customize the air-gap spacing between slats to balance privacy with site wind load parameters?

A4: Yes, completely. Because our aluminum framing sections are fully modular, the air gap intervals can be completely adjusted during layout configuration. We can supply interlocking spacing channels ranging from a 0mm total-privacy seal to custom 10mm, 20mm, or wider wind-ventilation windows to optimize the fence’s structural deflection profile matching your local engineering demands.

Precision Aluminum Manufacturing & Custom OEM/ODM Services

Expert in Aluminum Extrusion, Deep Processing, and Finished Products.

OEM & ODM aluminum extrusion manufacturing capabilities from Jiju Aluminium
